NA level 2 customization public electric vehicle ev charging stations

NA level 2 customization public electric vehicle ev charging stations

Short Description:

The EVC10 is designed for businesses. Delivering all the features you need to make EV charging easy, reliable and cost-effective. Our commercial EV charging solutions are available in four power levels (16a, 32A, 40A, and 48A). OCPP allow you to control your stations from an easy-to-use-dashboard, quickly onboard users and set charging prices.


  • Sample: Support
  • Customization: Support
  • Certification: ETL, FCC
  • Input Voltage: 208-240V
  • Output Rating: 16A/3.8KW , 32A/7.7KW , 40A/9.6KW , 48A/11.5KW
  • Charging Interface: SAE J1772 , Type1 Plug
  • Internal Communication: OCPP 1.6 JSON (OCPP 2.0 compatible)
  • External Communication: LAN (optional) + 4G (optional) or Wi-Fi (optional)
  • Charging Control: Plug & Play / RFID (ISO14443)
  • Cable Length: 18ft (25ft charging cable optional)
  • LCD Display: 4.3'' LCD Screen
  • Product Detail

    Product Tags

    Introduction

    We believe in: Innovation is our soul and spirit. Top quality is our life. Purchaser need is our God for Excellent quality China IEC 62196-2 11kw EV Recharge Stations EV Charger with Type 2 Outlet, Our tenet is evident all of the time: to deliver high quality solution at competitive price tag to clients throughout the planet. We welcome potential customers to get in touch with us for OEM and ODM orders.

    Product Specification

    JNT - EVC10
    Regional Standard
    Regional Standard NA Standard EU Standard
    Power Specification
    Voltage 208–240Vac 230Vac±10% (Single phase) 400Vac±10% (Three phase)
    Power / Amperage 3.5kW / 16A - 11kW / 16A
    7kW / 32A 7kW / 32A 22kW / 32A
    10kW / 40A - -
    11.5kW / 48A - -
    Frequency 50-60Hz 50-60Hz 50-60Hz
    Function
    User Authentication RFID (ISO 14443)
    Network LAN Standard (4G or Wi-Fi Optional with Surcharge)
    Connectivity OCPP 1.6 J
    Protection & Standard
    Certificate ETL & FCC CE (TUV)
    Charging Interface SAE J1772 , Type 1 Plug IEC 62196-2 , Type 2 Socket or Plug
    Safety Compliance UL2594 , UL2231-1/-2 IEC 61851-1 , IEC 61851-21-2
    RCD CCID 20 TypeA + DC 6mA
    Multiple Protection UVP , OVP , RCD , SPD , Ground Fault Protection , OCP , OTP , Control Pilot Fault Protection
    Environmental
    Operating Temperature -22°F to 122°F -30°C ~ 50°C
    Indoor / Outdoor IK08, Type 3 enclosure IK08 & IP54
    Relative Humidit Up to 95% non-condensing
    Cable Length 18ft (5m) Standard , 25ft (7m) Optional with Surcharge

    Product Details

    Charging Station Charging Station Charging Station Charging Station Charging Station Charging Station Charging Station Charging Station Charging Station
