DC Charging CE60KW

DC Charging CE60KW

Short Description:


Product Detail

Product Tags

AC & DC Integration

One charger with three outputs, simultaneously charging

One AC connector: Type 2, with output up to 43kW

Two DC connectors: CCS1/CCS2 and CHAdeMO, with output up to 60kW

Flexible Option

Adjustable output current up to 50A

RFID authentication, optional with plug and play

CCS2 charging cable, optional with CHAdeMO charging cable

Intelligent Control

Ethernet/4G/Wi-Fi communication all supported

OCPP communication protocol with CMS

Intelligent operation by App and cashless payment

Secure and Safe

Type A RCD for residual current protection

MID certified AC meter and PTB certified DC meter

ISO15118 prepared for advanced feature of Plug&Charge

Short Description:

DC 60kW Fast Charger meets the European charging standards for new energy electric vehicles. Power control, charging management, network communication and other customized functions, all in one device.

The entire charging process is under intelligent control, offering 150~500V output voltage range. CCS2 single gun charging offers super fast charging for one electric vehicle. CCS 2 dual guns charging allows the charging of two electric vehicles simultaneously with equal power distribution.

Key Features:

Power: 90kw

Output Current: Max.80A

Output Voltage: 200*750Vdc

One Type 2 charging socket

Two CCS2 charging gun

Self-developed power module

Compliant with OCPP 1.6 ( JSON)

RFID function

Protection Grade: IP54

Warranty: 3 years

Double waterproof & dustproof

Double-cavity design for module, maze design for air flow , double waterproof & dustproof design.

Professional cooling design

Bell-mouth direct ventilation solution, ensure the ventilation for the modules, control the internal temperature, enhance the efficiency and stability.

Core modules

Independently developed power module with our own patent, approved by 3rd party certification body

Stable and Reliable

Use industry’s top components and high-efficiency module to ensure the hardware stability and reliability.

Friendly operation

Full LCD touch screen display of working status, charging progress, card balance and other operation information.

Initiative protection

BMS depth interaction, charger active participation in the monitoring during the charging process, to ensure a safe charging.

High power fast charge

Super fast charge: Single gun output 100%, double guns at the same time charges an average of 50% per gun.

Specification Parameters

Specification Model DC060K-BE-20
AC Nominal Input Phases / Lines 3 phase + neutral + PE
Voltage 400 V ± 10%
Frequency 50Hz

DC Nominal Output

Voltage 200~750V
Current Max. 80A
Power 60KW
Electrical Parameter Power Factor ≧0.99 (50%~100% load)
THD Value ≦5% (50%~100% load)
Stable Voltage Accuracy ≦±0.5%
Stable Current Accuracy ≦±1%
Efficiency Max. 94%
Auxiliary Power 12V
Structure Design Housing Material Galvanized steel
Installation Method Floor-stand
Wall-mount Bracket NA
Charging Outlet Two charging guns (CCS Combo 2)
Cable Length 7M
LED Indicator 3 indicators
LCD Screen Yes
Emergency Stop Button Yes
Startup Mode Plug-and-play/RFID Card/QR Code
RFID Function Yes
Communication Charger v.s. EV PLC (DIN 70121: 2014-12)
EN-GATE v.s. Charger CAN
EN-GATE v.s. Backend Ethernet/4G/WIFI
Communication Protocol OCPP 1.6 (JSON)
Environmental Index Operating Temperature -30 °C ~ +50 °C
Working Humidity 5%~95% without condensation
Working Altitude <2000M
Protection Grade IP54
Application Site Indoor/Outdoor
Cooling Method Fan cooling
Noise ≦60dB
Safety Protection Multiple Protection Over/Under voltage protection, Overload protection, Short circuit protection, Over/Under temperature protection, Grounding protection, Surge protection
MTBF 100,000 hours
Safety Standard IEC 61851-1:2017, IEC 61851-23:2014
Warranty 1 years
Package Information Product Dimension 700*280*1600mm
Package Demension 800*380*1800MM
Net Weight 190KG
Gross Weight 230KG
External Packing Wooden case
