EU AC EV Charger Commercial Version Electric Car Charging Solar EV Station

EU AC EV Charger Commercial Version Electric Car Charging Solar EV Station

Short Description:

Home charging gives electric vehicle drivers peace of mind every day. Over half of EV drivers prefer to charge at home, and as more people convert to driving electric reliable home charging solutions are necessary. Joint Charging offers fast and reliable home charging solutions and we pride ourselves in having forward-thinking solutions ready to install today.


  • Sample: Support
  • Customization: Support
  • Certification: CE
  • Input Voltage: 230±10%(1- phase) or 400±10%(3- phase)
  • Output Power: 7KW , 11KW , 22KW
  • Charging Interface: IEC 62196-2 , Type2 Plug
  • Internal Communication: OCPP 1.6 JSON (OCPP 2.0 compatible)
  • External Communication: LAN (optional) + Wi-Fi (optional)
  • Charging Control: Plug & Play / RFID (ISO14443)
  • Cable Length: 18ft (25ft charging cable optional)
  • Product Detail

    Product Tags

    Introduction

    It can be our responsibility to satisfy your requirements and successfully serve you. Your pleasure is our greatest reward. We've been searching forward for your check out for joint expansion for Hot sale 11.5kw AC EV Charger Commercial Version Electric Car Charging Floor-Mounted Solar EV Station China Charging Stations, Seeing believes! We sincerely welcome the new customers abroad to set up business relationships and also expect to consolidate the relationships with the long-established customers.

    Product Specification

    JNT - EVC11
    Regional Standard
    Regional Standard NA Standard EU Standard
    Power Specification
    Voltage 208–240Vac 230Vac±10% (Single phase) 400Vac±10% (Three phase)
    Power / Amperage    3.5kW / 16A - 11kW / 16A
    7kW / 32A 7kW / 32A 22kW / 32A
    10kW / 40A - -
    11.5kW / 48A - -
    Frequency 50-60Hz 50-60Hz 50-60Hz
    Function
    User Authentication RFID (ISO 14443)
    Network LAN Standard (Wi-Fi Optional with Surcharge)
    Connectivity OCPP 1.6 J
    Protection & Standard
    Certificate ETL & FCC CE (TUV)
    Charging Interface SAE J1772 , Type 1 Plug IEC 62196-2 , Type 2 Socket or Plug
    Safety Compliance UL2594 , UL2231-1/-2 IEC 61851-1 , IEC 61851-21-2
    RCD CCID 20 TypeA + DC 6mA
    Multiple Protection UVP , OVP , RCD , SPD , Ground Fault Protection , OCP , OTP , Control Pilot Fault Protection
    Environmental
    Operating Temperature -22°F to 122°F -30°C ~ 50°C
    Indoor / Outdoor IK08, Type 3 enclosure IK08 & IP54
    Relative Humidit Up to 95% non-condensing
    Cable Length 18ft (5m) Standard , 25ft (7m) Optional with Surcharge

    Product Details

    EVC11详情页  (1) EVC11详情页  (1) EVC11详情页  (2) EVC11详情页  (3) EVC11详情页  (4) EVC11详情页  (5) EVC11详情页  (6) EVC11详情页  (7) EVC11详情页  (8)
